Polyurethane Casting
PU casting is also known as silicone rubber casting, or Room Temperature Vulcanization (RTV) casting. The mold material is silicone rubber and the cast material is PU.
The pattern for the mold is normally made by 3D printing or machining. One silicone rubber mold can cast 25-50 pieces of PU parts. The PU material consists of two parts in liquid form.
When the two parts are mixed and cast in a silicone rubber mold, they solidify. In silicone rubber mold casting, the PU takes from one to two hours to cure. The cost of a silicone mold is usually several times higher in unit price compared to the cast, but this is normally factored into the unit price of the cast itself. The PU casting method is preferred over the machining method in following scenarios:
- Lower the unit part cost when the volume goes higher;
- Make complex shapes that are not feasible by machining;
- Have special material requirements, such as transparency.
The PU casting process is ideal for low volume plastic parts. It saves clients from expensive and long lead-time production tooling. Also, PU casting allows certain complex shapes that are not attainable by injection molding because the silicone rubber mold is soft to allow large deformation to release the cast from the mold itself.
Silicone rubber mold for the Control Box, for Nytric Ltd.
The above picture shows the mold and the cast. The part has a large special undercut that cannot be done by injection molding.
